Figure 7: APCQ-M & APCQ-R internal layout
4.4. Power Factor Controllers
– RVC controller (by default if V ≤ 440V),
– RVT (optional if V ≤ 440V, otherwise provided by default).
Note: the Quick Start manual of the power factor controller is provided within the capacitor bank.
Figure 8: RVC and RVT Power Factor controllers
