APCQ CAPACITOR BANKS
© 2022 Hitachi Energy. All rights reserved
3.4. Packing & unpacking
By default, APCQ-L, APCQ-M and APCQ-R capacitor banks are delivered in carton box (standard packing, as per
Figure 3 here below). Optionally, wood crates and seaworthy can be used as per Figure 4 here below.
Figure 3: APCQ box with carton standard packaging
-L
-M & APCQ-R
Box dimensions (including pallet) (LxWxH)
To unpack APCQ-L capacitor bank with carton box:
– Remove the nails between the carton box and the pallet and remove the carton
– Remove fixation screws
To unpack APCQ-M and APCQ-R capacitor banks with carton box:
– Remove the carton box
– Remove fixation screws
Any damage on the packing or material must be immediately reported to your HITACHI ENERGY representative.
