6.9. Optional IP20 internal grid for APCQ-M and APCQ-R
On top of the plexiglasses provided by default (refer to 4.3), it is also possible to order an optional internal protection
grid.
Then, the APCQ-M/R cabinet will be IP20 open door.
Figure 38 Internal grid
6.10. Optional base frame (200 mm) and flanges (base frame covers)
The APCQ-M/R cabinets are delivered by default with 100 mm plots in the bottom and flanges. It is possible to order
a double-plots execution (200 mm high base) as per below picture.
