APCQ CAPACITOR BANKS
STATUS
Approved
SECURITY LEVEL
Public
DOCUMENT ID
9AKK107680A4136
RE V.
E
LANG.
en
PAGE
10/47
© 2022 Hitachi Energy. All rights reserved
.
4.3. APCQ capacitor banks internal layout
Number
APCQ
-L Description
1
Fan (air outlet)
2
Auxiliary transformer
3
Auxiliary connections (current transducer)
4
Power Factor Controller (RVC by default or RVT as an option)
5
UA contactors
6
Busbar point of connection (3
-Phase)
7
QCap capacitors
8
Internal protection Plexiglas
9
Air
inlet
10
Circuit breaker (optional)
11
Thermal cutoff switch
12
Cable knock
-out
13
Temporary carton fixations to be removed during commissioning
