6.7. IP54 design
IP54 design is made with additional fans located in the door.
Air inlet and outlet are both located in the front door: air inlet in the bottom, air outlet in the top.
Figure 35: IP54 design
Figure 36: Location of thermal cutoff switch in IP54 layout
