6.8. Wooden crates and Seaworthy packing
This special packing is required when intercontinental or multi-modal shipment.
Such crates better guarantees a safer shipment.
Different size of crates are used for one, two, three and four cabinets.
Below picture show an example of crates for two cabinets.
Figure 37 Wooden crate with seaworthy packing for 2 APCQ-R/M cabinets
Seaworthy packing dimensions and weight with APCQ cabinets
Crate for one cabinet
Aprox 1200x800x2400 mm (WxDxH)
– 650 kg
Crate for two cabinets
Aprox
2000x800x2400 mm (WxDxH) – 1300 kg
Crate for three cabinets
Aprox 2000x2000x2400 mm (WxDxH)
– 1950 kg
Crate for four cabinets
Aprox 2000x2000x2400 mm (WxDxH)
– 2600 kg
