APCQ CAPACITOR BANKS
STATUS
Approved
SECURITY LEVEL
Public
DOCUMENT ID
9AKK107680A4136
RE V.
E
LANG.
en
PAGE
26/47
© 2022 Hitachi Energy. All rights reserved
.
Figure 30: Optional circuit breaker connection – APCQ-M and APCQ-R, top or bottom entry
201.5mm
Figure 31: Connection with circuit breaker – APCQ-L
