Figure 7-9 Logical Processors Configuration Screen
The following table shows the descriptions of all the items displayed in the
Logical Processor configurations screen.
Table 7-9 Details of Logical Processors Configuration Screen
No. Item Description
Default
Value
Supported
LPAR
manager
Version
(1) # Displays LPAR numbers. - 01-0X~
(2) Name Displays LPAR names. NO_NAME 01-0X~
(3) Sta Displays LPAR status.
Act (Activate): the power is on.
Dea (Deactivate): the power is off.
Fai (Failure): Not available due to
unrecoverable failure.
Reboot LPAR manager when this happens.
If rebooting LPAR manager cannot solve
the problem, contact the reseller from
which you purchased this equipment or
consult maintenance personnel.
Dea 01-0X~
(4) Scd Sets a scheduling mode.
S: Shared mode
D: Dedicated mode
D 01-0X~
(5) Pro Displays the number of logical processors
assigned to the LPAR.
1 01-0X~
Operation by LPAR manager Screen
7-29
Hitachi Compute Blade 500 Series Logical partitioning manager User's Guide
