From port To port/host
Cable
length
Enclosure 10 IOM A host 1 Server module 2 port 6 4 meters
Enclosure 10 IOM B host 1 Server module 1 port 6 4 meters
Enclosure 11 IOM A host 1 Server module 1 port 4 4 meters
Enclosure 11 IOM B host 1 Server module 2 port 4 4 meters
Enclosure 12 IOM A host 1 Server module 2 port 8 4 meters
Enclosure 12 IOM B host 1 Server module 1 port 8 4 meters
Enclosure 13 IOM A host 1 Enclosure 9 IOMAhost 5 3 meters
Enclosure 13 IOM B host 1 Enclosure 11 IOMB host 5 3 meters
Enclosure 14 IOM A host 1 Enclosure 10 IOMAhost 5 3 meters
Enclosure 14 IOM B host 1 Enclosure 12 IOMBhost 5 3 meters
Enclosure 15 IOM A host 1 Enclosure 11 IOMA host 5 4 meters
Enclosure 15 IOM B host 1 Enclosure 9 IOMB host 5 4 meters
Enclosure 16 IOM A host 1 Enclosure 12 IOMAhost 5 4 meters
Enclosure 16 IOM B host 1 Enclosure 10 IOMB host 5 4 meters
(Continued)
Each enclosure has two SAS cable connections. When connecting the cables,
connect both cables for an enclosure before proceeding to the next
enclosure.
To connect the SAS cables for an enclosure, for each cable:
1. Connect one end of the cable to the applicable host port on the enclosure
for which you're connecting the cables. When inserting the cable into the
host port, push the end of the cable until the connector clicks into place.
2. Connect the other end of the cable to the applicable port in the
applicable server module or the applicable host port in the applicable
other enclosure. When inserting the cable into the port or host port,
push the end of the cable until the connector clicks into place.
72
Chapter 4: Refurbishing an HCP S30 Node
HCP S Series Node Refurbishment
Step 5: Cable the enclosures
