Hitachi DVPF2E - Automatic Tuning; Manual Tuning

Hitachi DVPF2E
57 pages
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
3 Press the B or C Button to select CH TUN-
ING, then press the
g Button.
4 Press the B or C Button to select MANU-
AL, then press the
g
Button.
5 Press the B or C Button to select POSI-
TION, then press the
g Button.
When a weak signal is received in Manual Tuning
mode, you can change the background to solid blue
or the static screen by pressing the C. RESET
Button.
6 Press the Number, B, or C Button to select
your desired position number, then press
the
g Button.
You can select position number 01-99.
If [ON] appears on the right side of SKIP, press the
B or C Button to point to SKIP. Then, press the
g Button to select [OFF].
If you want to remove scrambled signals, press the B
or C Button repeatedly to point to DECODER.
Then, press the g Button to select [ON].
7 Press the B or C Button to select CHAN-
NEL, then press the
g Button.
8 Press the B or C Button to start scanning.
The DVD/VCR tuner will begin to search up or down
automatically. When a channel is found, the
DVD/VCR will stop searching and the picture will
appear on the TV Screen.
You can select desired channel number by using the
Number Buttons. You must refer to the channel plan
and press three digits to select the channel number.
(To select channel 24, first press the 0 Button and
then press 2 and 4).
If this is the channel you want, press the
g
Button.
9 Press the MENU Button to exit.
Note
To confirm that a channel has been added, press the
CH Buttons (o/p).
22
EN
2C15
You can programme the tuner to scan only the chan-
nels that you can receive in your area.
Use the remote control for this procedure.
1 Turn on the TV and select the TV channel to
the video channel on the TV.
2 Press the MENU button.
3 Press the B or C Button to select INI-
TIAL, then press the
g Button.
4 Press the B or C Button to select CH TUN-
ING, then press the
g Button.
5 Press the B or C Button to select AUTO,
then press the
g Button.
The tuner scans and memorises all the active chan-
nels in your area. After scanning, the tuner stops on
the lowest memorised channel.
To Select a Desired Channel
You can select a desired channel by using
the CH Buttons (o/p), or directly pressing the
Number Buttons on the remote control.
Enter a channel numbers as a two-digit number for
the quickest results. For example, to select channel
6, press 0 and 6. If you only press 6, channel 6 will
be selected after a brief delay.
You can only select channels 199.
VCR
MENU
TIMER
SET UP
INITIAL
INITIAL
CH TUNING
CLOCK
RF OUT
CH TUNING
AUTO
MANUAL
MOVE
Use the remote control for this procedure.
1 Press the MENU Button.
2 Press the B or C Button to select INI-
TIAL, then press the
g Button.
VCR
MENU
TIMER
SET UP
INITIAL
INITIAL
CH TUNING
CLOCK
RF OUT
CH TUNING
AUTO
MANUAL
MOVE
MANUAL
POSITION
CHANNEL
DECODER
SKIP
P08
008
[OFF]
[OFF]
Channel Plan
CH Indication TV Channel
01 10 IRA-IRJ, gap
21 69 E21 E69
74 78 S01
~ S03, X, Y
80 100 S1 S20, gap
121 141 S21 S41
AUTOMATIC TUNING
MANUAL TUNING
