¿ Anti-bacteria filter (F-23L4-K)
The dimensions of the long-lasting anti-bacteria filter are shown in
the following figure.
To fit the filter, insert the tab on the suction grille into the large hole
in the filter, as shown in the figure below.
Model
a (mm)
RCI-(1.5-2.5)FSN2E 248
RCI-(3.0-6.0)FSN2E 298
N O T E
When using this filter, set the air flow to high speed using the
remote control to maintain the necessary volume of air.
Specifications
Part
RCI-(1.0-6.0)
Dust collection efficiency (%) 50 (gravimetric method)
Air flow rate (m
3
/min) 37.0
Initial pressure loss Pa (mmAq) 17.7 (1.8)
Final pressure loss Pa (mmAq) 44.1 (4.5)
Filter/Frame/Packaging colour White/Brown/-
Working life 4 years (with maintenance every 1250 hours)
Cleaning Available
(*)
Weight (kg) 0.7
Performance Avoids the multiplication of bacteria and mould
Filter material:
Modified acrylic fibre 1 (containing inorganic anti-bacterial
substance)
Support net
Modified acrylic fibre 2 (containing organic anti-bacterial
substance)
(*)
This is the standard working life of the filter and its duration may vary depending on the conditions of use. Clean the filter
with water or neutral detergent.
2 Unit installation
74
SMGB0063 rev. 1 - 10/2010
