¿ Deodorising filter (F-23L4-D and F-46L4-D)
The dimensions of the deodorising filter are indicated in the
following figure.
Remember that the filter thickness depends on the model.
Model a (mm)
RCI-(1.5-2.5)FSN2E 26
RCI-(3.0-6.0)FSN2E 42
To fit the filter, you must install the filter box Filter box (B-23H4), see on page 73.
N O T E
When using this filter, set the air flow to high speed using the remote control to maintain the necessary volume of
air.
Specifications
Part
RCI-(1.0-2.5) F-23L4-D RCI-(3.0-6.0) F46-L4D
Dust collection efficiency (%) 50 (gravimetric method)
Air flow rate (m
3
/min) 20.0 37.0
Initial pressure loss Pa (mmAq) 15.7 (1.6) 16.7 (1.7)
Final pressure loss Pa (mmAq) 42.2 (4.3) 33.3 (3.4)
Working life 3 years (with maintenance every 3-6 months)
Reuse Available (dried by sunlight)
(*1)
Cleaning Available (washed with water)
(*2)
Weight (kg) 0.9 1.0
Dimensions a (mm) 0.9 1.0
Performance Absorbs smoke, body odour, etc.
Restrictions of use Washing with detergents is forbidden
(*1)
This is the standard working life of the filter and its duration may vary depending on the conditions of use. Clean the
filter with water or neutral detergent.
(*2)
Wash the filter with water or neutral detergent to avoid reducing the absorption capacity.
N O T E
• Some special smells (such as that of organic solvents and sulphur gas) cannot be eliminated.
• This filter is reusable. Clean as indicated in the table and allow to dry in the sun.
• This filter can be used with the long-lasting deodorising filter (optional).
• This filter is supplied individually.
2 Unit installation
75
SMGB0063 rev. 1 - 10/2010
