Chapter 4 Explanation of Functions
4-159
Register No.
Function name
Function code
R/W
Monitoring and setting items Data resolution
Data
resolution
1633h
Motor poles setting for RPM
P049
R/W
0 (0 pole), 1 (2 poles), 2 (4 poles), 3 (6 poles),
4 (8 poles), 5 (10 poles), 6 (12 poles), 7 (14
poles), 8 (16 poles), 9 (18 poles), 10 (20
poles), 11 (22 poles), 12 (24 poles), 13 (26
poles), 14 (28 poles), 15 (30 poles), 16 (32
poles), 17 (34 poles), 18 (36 poles), 19 (38
poles)
-
1634h to
1638h
(Reserved)
-
-
Inaccessible
-
1639h
Pulse train frequency scale
P055
R/W
10 to 500 (input frequency corresponding to
the allowable maximum frequency)
0.1 [kHz]
163Ah
Time constant of pulse train frequency filter
P056
R/W
1 to 200
0.01 [sec.]
163Bh
Pulse train frequency bias
P057
R/W
-100 to +100
1 [%]
163Ch
Pulse train frequency limit
P058
R/W
0 to 100
1 [%]
163Dh
(Reserved)
-
-
Inaccessible
-
163Eh
Multistage position setting 0
P060(HIGH)
R/W
1
163Fh
P060(LOW)
R/W
1640h
Multistage position setting 1
P061(HIGH)
R/W
1
1641h
P061(LOW)
R/W
1642h
Multistage position setting 2
P062(HIGH)
R/W
1
1643h
P062(LOW)
R/W
1644h
Multistage position setting 3
P063(HIGH)
R/W
1
1645h
P063(LOW)
R/W
1646h
Multistage position setting 4
P064(HIGH)
R/W
1
1647h
P064(LOW)
R/W
1648h
Multistage position setting 5
P065(HIGH)
R/W
1
1649h
P065(LOW)
R/W
164Ah
Multistage position setting 6
P066(HIGH)
R/W
1
164Bh
P066(LOW)
R/W
164Ch
Multistage position setting 7
P067(HIGH)
R/W
1
164Dh
P067(LOW)
R/W
164Eh
Zero-return mode selection
P068
R/W
0(Low) / 1(High1) / 2(High2)
164Fh
Zero-return direction selection
P069
R/W
0(FW) / 1(RV)
1650h
Low-speed zero-return frequency
P070
R/W
0 to 1000
1651h
High-speed zero-return frequency
P071
R/W
0 to 40000
1652h
Position range specification (forward)
P072(HIGH)
R/W
0 to 536870912 (when P012 = 2) /
0 to 2147483647 (when P012 = 3)
1
1653h
P072(LOW)
R/W
1654h
Position range specification (reverse)
P073(HIGH)
R/W
-536870912 to 0 (when P012 = 2) /
-2147483647 to 0 (when P012 = 3)
1
1655h
P073(LOW)
R/W
1656h to
1665h
(Reserved)
-
-
Inaccessible
-
1666h
Easy sequence user parameter U (00)
P100
R/W
0 to 65530
1
1667h
Easy sequence user parameter U (01)
P101
R/W
0 to65530
1
1668h
Easy sequence user parameter U (02)
P102
R/W
0 to 65530
1
1669h
Easy sequence user parameter U (03)
P103
R/W
0 to 65530
1
166Ah
Easy sequence user parameter U (04)
P104
R/W
0 to 65530
1
166Bh
Easy sequence user parameter U (05)
P105
R/W
0 to 65530
1
166Ch
Easy sequence user parameter U (06)
P106
R/W
0 to 65530
1
166Dh
Easy sequence user parameter U (07)
P107
R/W
0 to 65530
1
166Eh
Easy sequence user parameter U (08)
P108
R/W
0 to 65530
1
166Fh
Easy sequence user parameter U (09)
P109
R/W
0 to 65530
1
1670h
Easy sequence user parameter U (10)
P110
R/W
0 to 65530
1
1671h
Easy sequence user parameter U (11)
P111
R/W
0 to 65530
1
1672h
Easy sequence user parameter U (12)
P112
R/W
0 to 65530
1
1673h
Easy sequence user parameter U (13)
P113
R/W
0 to 65530
1
1674h
Easy sequence user parameter U (14)
P114
R/W
0 to 65530
1
1675h
Easy sequence user parameter U (15)
P115
R/W
0 to 65530
1
1676h
Easy sequence user parameter U (16)
P116
R/W
0 to 65530
1
1677h
Easy sequence user parameter U (17)
P117
R/W
0 to 65530
1
1678h
Easy sequence user parameter U (18)
P118
R/W
0 to 65530
1
1679h
Easy sequence user parameter U (19)
P119
R/W
0 to 65530
1
167Ah
Easy sequence user parameter U (20)
P120
R/W
0 to 65530
1
167Bh
Easy sequence user parameter U (21)
P121
R/W
0 to 65530
1
167Ch
Easy sequence user parameter U (22)
P122
R/W
0 to 65530
1
167Dh
Easy sequence user parameter U (23)
P123
R/W
0 to 65530
1
167Eh
Easy sequence user parameter U (24)
P124
R/W
0 to 65530
1
167Fh
Easy sequence user parameter U (25)
P125
R/W
0 to 65530
1
