1.3.4 Print data registration transmission
1.3.4-1 Text
● Specifies message number
ESC2
Header 21H
Classification 31H
1000s place
100s place
10s place
Unit
place
● Specifies registration No. and message name.
ESC2
Header 21H
Classification 31H
1000s place
100s place
10s place
Unit
place
ESC2
Header 21H
Classification 32H
Message name (1 to 12 digits)
1.3.4-2 Message name
(1) Message number specified
●A message name is automatically attached when print data is registered.
● Based on the message name displayed in the upper left hand corner of the screen,
the last 4 digits are replaced with the message number and used as the new message name.
(Example) Registering for No. 123
Contents displayed in upper left hand corner of the screen: "ABCDEFGHIJKL"
Message name after registration : "ABCDEFG 0123"
(2) Message number and message name specified
●The specified message name attached when print data is registered.
(3) Same message name is used for other message number
●If a message name is in use for other message number, new message name will be created by
using original message name as a base and replacing its 7th and 8th digits with AA~ZZ.
(Example) Message name [ABC] is already registered on No.1. Register on No.2 using identical
message name.
Message name of No.1: [ABC]
Message name of No.2: [ABC AA]
(4) Characters available for message name
●Characters used for setting the message name transmission are different from characters used in manual
input on registration screen.
Function
Alphameric character/Symbols
Accent character/
Arabic character
Manual input
Available
Available
Message name transmission
Available
Unavailable
Print data message number (0001 to 2000)
(Contd.)
Print data message number (0001 to 2000)
Message name: ASCII code (20H to 5FH, 61H to 7AH)
Numbers/symbols (ASCII code): 20H to 5FH, 61H to 7AH
