1.3.5-4 Example of print conditions transmission
(1) Example where print item is not specified
02H
1FH
22H
32H
31H
30H
1FH
25H
36H
30H
31H
32H
33H
03H
STX
ESC2
“
2
1
0
ESC2
%
6
0
1
2
3
ETX
[Transmission results]
All print items are set as 1 stage, write position is changed to 0123.
(2) Example where print item is specified
02H
1FH
70H
31H
1FH
23H
31H
34H
30H
30H
STX
ESC2
p
1
ESC2
#
1
4
0
0
[Transmission results]
Upper stage character size is changed
1FH
70H
33H
1FH
23H
31H
34H
30H
30H
03H
ESC2
p
3
ESC2
#
1
4
0
0
ETX
➀
➂
②
➃
➀
➂
②
➃
Header,
classification
Line count 1
line spacing 0
Header,
classification
Write position 123
Header, item No
Character size 7×10,
inter-character space 0
Header,
classification
Header, item No
Header,
classification
Character size 7×10,
inter-character space 0
(Contd.)
