OPERATOR'S STATION
1-76
Armrest Adjustment
Armrest (6) can be pulled upright by hand to get on and off
the machine easily.
The angle of armrest (6) can be adjusted to the desired posi-
tion by turning adjusting dial (7) located on the bottom of
armrest (6).
SEAT WITH A BUILT-IN HEATER
The heater installed inside the seat activates by operating seat
heater switch (8) on the optional equipment control switch
panel.
NOTE: Depending on what kinds of optional equipments are
installed, the switch button function may differ. Use the
switch only after confirming the kinds of the installed
optional equipment.
M1G6-01-017
6
7
M1U1-01-011
8
To Next Page
