OPERATOR'S STATION
1-48
WORK LIGHT SWITCH
Work light switch has the following positions:
• 1 Position
Work light (1) on the base machine will light. Also, the
instrument panel illumination will light.
• 2 Position
Work light (2) will light in addition.
• OFF Position
Work lights (1) and (2) and the instrument panel illumina-
tion will turn off.
M178-01-015
M157-01-146
2
1
