OPERATOR'S STATION
1-8
Hour Meter
Total (accumulated) machine operation hours counted since
the machine started working, are displayed in the unit of HOUR
(h). One digit after the decimal point indicates the tenths of an
hour (6 minutes).
Fuel Gauge
The fuel amount in the fuel tank is indicated. Refuel before the
needle reaches “E”.
Clock
Indicates the present time.
Back Monitor Selector
Shifts the monitor screen to the back view monitor screen and
vice versa.
M1U1-01-039
M81U-01-058
M1U1-01-041
M1U1-01-040
