OPERATING THE MACHINE
5-21
• Do not operate the breaker in water. Doing so will cause
rust and seal damage, resulting in damage to the hydrau-
lic system components.
• Do not use breaker for lifting operation. The machine tip
-
ping over and/or breaker damage may result.
• Do not operate the breaker to the side of the machine.
The machine may become unstable and undercarriage
component life may shorten as a result from operating
the breaker to the side of the machine.
• Operate the hydraulic excavator carefully to avoid hitting
the boom.
M104-05-059
M104-05-060
M104-05-061
M104-05-062
WRONG
WRONG
WRONG
Watch Out!
Take care not to hit the
boom with the breaker
WRONG
RIGHT
RIGHT
WRONG
Rod
To Next Page
