MAINTENANCE
7-54
16. When replacing the air cleaner filter element, replace
both outer (1) and inner (3) elements together. Remove
outer element (1). Clean the filter interior before remov-
ing inner element (3). Remove inner element (3). First
install inner element (3) and then install outer element (1).
IMPORTANT: Do not reuse inner element (3). Always re
-
place the new one.
M157-07-061
Air Restriction Switch
1
Valve
3
Cover
