MAINTENANCE
7-67
•
Fusible Link (Main Fuse)
In case the starter will not rotate even if the key switch is
turned to the START position, fusible link may the cause of
the trouble. Remove the cover next to the engine coolant
reservoir to check the fuse. Replace it if blown.
21- + Side (Red)

45A
22- − Side (Black)

65A
M1U1-07-023
21
22
Battery
