SPECIFICATIONS
12-39
SHOE TYPES AND APPLICATIONS
ZX350LC-3
Shoe Width
600 mm (24”)
Grouser Shoe
700 mm (28”)
Grouser Shoe
800 mm (31”)
Grouser Shoe
600 mm (24”)
Flat Shoe
Application
For Ordinary Ground
(Standard)
For Weak Footing
(Option)
For Weak Footing
(Option)
For Paved Road
(Option)
Operating Weight kg
(lb)
33300
(73400)
33700
(74300)
34100
(75200)
34000
(75000)
Base Machine Weight kg
(lb)
25500
(56200)
25900
(57100)
26200
(57800)
26200
(57800)
Cab Height mm
(ft•in)
3140
(10’4”)
3140
(10’4”)
3140
(10’4”)
3140
(10’4”)
Minimum Ground mm
Clearance (ft•in)
500
(20”)
500
(20”)
500
(20”)
540
(21”)
Undercarriage mm
Length (ft•in)
4940
(16’3”)
4950
(16’3”)
4950
(16’3”)
4950
(16’3”)
Undercarriage Width mm
(ft•in)
3190
(10’6”)
3290
(10’10”)
3390
(11’1”)
3190
(10’6”)
Ground Pressure
63 kPa
(0.64 kgf/cm
2
,
9.1 psi)
54 kPa
(0.55 kgf/cm
2
,
7.8 psi)
48 kPa
(0.49 kgf/cm
2
,
7.0 psi)
64 kPa
(0.65 kgf/cm
2
,
9.2 psi)
ZX350LCN-3
Shoe Width
600 mm (24”)
Grouser Shoe
700 mm (28”)
Grouser Shoe
800 mm (31”)
Grouser Shoe
600 mm (24”)
Flat Shoe
Application
For Ordinary Ground
(Standard)
For Weak Footing
(Option)
For Weak Footing
(Option)
For Paved Road
(Option)
Operating Weight kg
(lb)
33200
(73200)
33600
(74100)
34000
(75000)
33900
(74700)
Base Machine Weight kg
(lb)
25400
(56000)
25800
(56900)
26200
(57800)
26100
(57500)
Cab Height mm
(ft•in)
3140
(10’4”)
3140
(10’4”)
3140
(10’4”)
3140
(10’4”)
Minimum Ground mm
Clearance (ft•in)
500
(20”)
500
(20”)
500
(20”)
540
(21”)
Undercarriage mm
Length (ft•in)
4940
(16’3”)
4950
(16’3”)
4950
(16’3”)
4950
(16’3”)
Undercarriage Width mm
(ft•in)
3000
(9’10”)
3100
(10’2”)
3200
(10’6”)
3000
(9’10”)
Ground Pressure
62 kPa
(0.63 kgf/cm
2
,
9.0 psi)
54 kPa
(0.55 kgf/cm
2
,
7.8 psi)
48 kPa
(0.49 kgf/cm
2
,
7.0 psi)
64 kPa
(0.65 kgf/cm
2
,
9.2 psi)
NOTE: • The specifications for the front-end attachment are for 3.2 m (10 ft 6 in) arm with PCSA 1.4 m
3
(1.83 yd
3
) bucket.
• 700 mm (28 in) grouser shoe, 800 mm (31 in) grouser shoe and 600 mm (24 in) flat shoe should not be used on grav
-
el or rocky ground.
• The dimensions do not include the height of the shoe lug.
