Hitron CODA-4x8x User’s Guide
Figure 59: The Advanced: RIP Control Screen
The following table describes the labels in this screen.
Table 47: The Advanced: RIP Control Screen
RIP Interface Use this field to control the interface on which RIP
networking should occur.
Select WAN to exchange RIP information on the
CODA-4x8x’s Cable connection.
Select RF to exchange RIP information on the
CODA-4x8x’s wireless network.
RIP Send Version Use this field to control the type of RIP information to be
sent on the specified interface.
Select Do not send to have the CODA-4x8x not
send RIP information.
Select RIP 1 to send only RIP version 1
information.
Select RIP 2 to send only RIP version 2
information.
Select RIP 1/2 to send both RIP version 1 and
version 2 information.
