A99UE13-1304
30
When you press the “▽” key, the extension tube of actuator will draw inward
(Please refer to the gure below.).
3. LAP4G use guide :
Align key with knob (Fig. 1)，to turn left enables the actuator；to turn right disables
the actuator.
Warning : Please stop turning while the key applied to the knob rotates about 45°，
otherwise，the key will be damaged；the same situation in the opposite direction.
Fig. 2. is a reference angle.
Fig. 2
Fig. 1
