1.Product Specication and Operation Environment
1. LAK2LR Series:
1.1 LAK2LR can combine uniaxial linear actuator with external limit switch.
1.2 The output power of a controller is 108VA (The output voltage is 24VDC.).
1.3 Fuse specication：2A/20mm(220/230VAC)，
3A/20mm(100/110VAC).
Chapter 2 LAK Series Controller User's Guide
6.1.Be sure the release cable is normal extended without any crooked when assembling,
and the end of wire is certainty xed on the mechanisms or hospital beds.
6.2.To avoid mistake touching, please put up warning notice on the mechanism or
facilities.
6.3.The way to active quick-release is pulling the handle and let the wire extend as the
following drawing.
6.4.Please lift the load temporary before active quick-release function, thus can pull the
wire out and separate the clutch mechanism.
6.5.Be sure to keep the clutch separated and restore the load on actuator, and the load
can extend and retract along axis direction.
6.6.The load on actuator cannot be the operating staff himself.
6.7.Be sure the release handle and clutch mechanism are restored by extending or
retracting the actuator after quick-release function is actived.
