※Use for medical beds with safety working load of 2000 N.
※The normal life time of hospital bad in operation equipment estimated ve to ten years.
(The hospital bad be used ve times per day)
◎ Operating temperature: +5°C ~ +40°C (+41°F ~ +104°F).
◎ Type of protection of applied parts against electric shock is BF.
◎ The temperature of Products under storage and transmission is: -10℃~+50℃.
◎ This product can not be used in chemical burdened environment.
◎ This product can not be used in environment of hyper electromagnetic wave and hyper
electromagnetic eld.
◎ Maximum weighted sound power level: 52 dB(A)
◎ If the LAN5(Quick Release Function) is damaged before installing or using. Please
turning power off rst and immediately contact us or agent of HIWINMIKRO.
◎ If LAN5 (Quick Release Function) used with hospital bad, have to make sure wire
placed location. The wire does not placed aside, in order to avoid end user and
prevent touch mistake injured …etc.
Controller Handset
Type LAK4D-DDDD-230-GE LAP4G-4-GE
Controller power（Vin） AC 230 V --
Controller power（Vout） DC 24 V --
IP 54 54
Duty Cycle 10%（Max. 2 min On） --
Protection Class Class II
Actuator
Type LAN5-41-1-405-24GE LAN5-21-1-60-24GE LAN5-21-1-110-24GE
Max. Force 3000N（Motor = 3500 rpm） 6000N 6000N
Max. Self-
locking
3400N 6000N 6000N
Max. speed 9.5mm/s（Load = 0） 4.5mm/s（Load = 0） 4.5mm/s（Load = 0）
Stroke 405mm 60mm 110mm
Power Rating 24V，Max. 4 Amp 24V，Max. 4 Amp 24V，Max. 4 Amp
IP 54 54 54
Duty Cycle 10%（Max. 2 min On） 10%（Max. 2 min On） 10%（Max. 2 min On）
Function of the
medical bed
Adjust the bed surface
horizontal height
（1）Adjust the back.
（2）Adjust the leg.
（3）Adjust the surface
horizontal gradient.
（1）Adjust the back.
（2）Adjust the leg.
（3）Adjust the surface
horizontal gradient
Chapter 7 Product use in Medical Bed
1. Special features
