Hiwin LAS3-1 User Manual

5
A99UE13-1304
TYPE
Max.
Push Force
(N)
Max.
Pull Force
(N)
Max. Current (A)
Max
Holding
Force (N)
Speed (mm/s)
12VDC 24VDC
LAM1-1 4000 3000 12 6 4000 8-11
LAM1-2 2000 2000 12 6 1200 16-21
LAM1-1A 3000 3000 12 6 3000 8-11
LAM2-1 3500 3500 8 4 3000 2-3.5
LAM2-2 2500 2500 8 4 2000 3-6
LAM2-3 1500 1500 6 3 1500 6.5-12
LAM2-4 1200 1200 6 3 800 8-14
LAM3-1 6000 5000 12 6 5000 4-5.5
LAM3-2 4000 4000 10 5 4000 5.5-7.5
LAM3-3 3000 3000 8 4 3000 7-9
LAM3-4 2000 2000 8 4 1500 11.5-14.5
LAI1-1 4000 4000 8 4 1200 6-9
LAI1-1A 4000 4000 10 5 3000 6-9
LAI2-1 12000 10000 3 12000 2-2.5
LAI2-2 8000 8000 4 8000 4-5
LAS1-1 1200 1200 6 2.5 800 8-12
LAS1-2 600 600 6 3 300 16-25
LAS2-1 1800 1200 6 3 1800 4.5-7
LAS2-2 1200 1200 6 4 1000 8-15
LAS3-1 1200 1200 6 2.5 800 8-12
LAS3-2 600 600 6 3 300 16-25
LAS4-1 800 800 5 2.3 600 10-15
LAS4-2 300 300 6 3.6 200 30-46
LAS5-1 800 800 1 600 2.5-4
LAS5-2 300 300 1 200 6-7.5
LAS5A-1 2000 2000 2.3 1500 2.5-4
LAS5A-2 1200 1200 2.3 800 7-8.5
LAN1-1
6000 5000 11 24VDC 24VDC(24Q)
5000
24VDC 12VDC 24VDC(24Q)
5000(12V) 5000(12V) 11 4 6 2.7-5 3-6 5-7
1. Product Specication
1.1 Standard Performance:
Chapter 1 Linear Actuator LA Series User's Guide

Hiwin LAS3-1 Specifications

General

Brand	Hiwin
Model	LAS3-1
Category	Controller
Language	English
