1.2. Input Voltage: 24VDC or 12 VDC; tolerance ±10%. The rated voltage of actuator is
indicated in the label or enclosed document.
1.3. Rated Duty Cycle: 10%
Denition: 2mis work and 18min pause.
1.4. Protection Class: IP54 (if not specially indicated)
1.5. Operating Temperature: +5℃ ~ +40℃ (+41°F ~ 104°F)
1.6. Atmospheric Pressure 860~1060hpa(12.5~15.4psi).
1.7. Equipment not suitable for use in the presence of a flammable anesthetic mixture
with air or with oxygen or nitrous oxide.
*The specication of LAH1 refers LAN1.
LAN1-2 4000 4000 11 4 6 4000 5-7 4-8 7-9
LAN1-3 3000 3000 10 4 6 3000 5-10 9-11.5
LAN1-4 2000 2000 5.5 2000 12-17
LAN2-1A 6000 6.5 5000 4-6
LAN2-2A 5000 6.5 5000 5-7.5
LAN2-3A 3000 6.5 3000 9-14
LAN3-1 10000 6000
24VDC 24VDC(24Q)
10000
24VDC 24VDC(24Q)
8.3 12 4.5-8 7-11
LAN3-2 7000 6000 8 11 7000 6.5-9 9-13
LAN3-3 5000 5000 7 11 5000 9-12.5 13-18
LAN3A-1 12000 6000 8.3 12 12000 3-5 4.5-7
LAN3A-2 10000 6000 8.3 12 10000 4.5-8 7-11
LAN3A-3 7000 6000 8 12 7000 7-9 9-13
LAN3A-4 5000 5000 7 12 5000 9.5-12.5 13-18
LAN4-1 3500 3500 12 6 3500 3.5-7
LAN4-2 3000 3000 12 6 3000 4.2-9
LAN4-3 2000 2000 12 5 2000 6-13
LAN4-4 1500 1500 12 5 1500 8.5-20
LAN5-1
8000
4000
24VDC 24VDC(24Q)
6000
24VDC 24VDC(24Q)
7000(24Q) 5 8 2-3.5 5-7
LAN5-2 6000 4000 4.5 8 5000 3-4.5 7-9
LAN5-3 4000 3000 4 6 4000 4-5.5 9-11
LAN5-4 3000 2000 4 6 1500 6-9 14-19
LAC1 2000 500 5 8 2000 8-12 13-16
LAC3 2000 500 5 2000 8-12
