A99UE13-1304
58
3. LAP3N Wiring
For LAK2BN
DIN connector
WIRING
LAK2BN
Speci
cation
1
GRA
Y
1UP
220mA
2
BLACK
1DN
--
3
WHITE
2UP
10mA
4
YELLOW
2DN
10mA
5
GREEN
LED_GREEN
50mA
6
BLUE
LED_YELLOW
50mA
7
BROWN
LED_RED
50mA
8
RED
DC_24V
50mA
9
SHELL
GND
10mA
SW1
1-UP
SW2
1-DN
SW3
2-UP
SW4
2-DN
D1
POWE
R-RE
D
R1
D2
GREE
N
D3
YELL
OW
D4
RED
BLUE
BROW
N
WHITE
GRAY
SHELL
BLACK
YELLO
W
GREEN
RED
Wiring Speci
cation
5
8
4
3
2
1
6
7
SHELL
Ø 13.25mm
45
0
0.7mm
57
59
