1. According to the axial number of actuator and the type of controller, a key box
can only match with corresponding linear actuator.
Example 1: Use a two-key box when combining a linear actuator (Please refer to the
gure below.).
Linear Actuator 1
Linear Actuator 2
Linear Actuator 3
Linear Actuator 4
4.Basic Operation Guide
2. When you press the “△” key, the extension tube of actuator will extend outward
(see a gure below).
