EtherNet/IP 6-8
© 2005 HMS Industrial Networks. AB7607 User manual
36 4 ASCII[4] Status Display Mimics a 4-character alpha-numeric
display.
If there are no faults, the display indi-
cates the Anybus-X MAC ID and its
Run/Idle status.
If there are faults, the display will
scroll through the MAC IDs of the
faulted nodes and display the error
code associated with each. See
Table 10-6, “Node Status Codes,” on
page 10-5 for a list of error codes.
40 1 USINT Anybus-X MAC
ID
The DeviceNet MAC ID of the Any-
bus-X.
41 1 USINT Scanner Status The current status of the DeviceNet
scanner. See Table 10-6, “Node Status
Codes,” on page 10-5 for a list of sta-
tus and error codes.
42 1 USINT Scrolling MAC
ID
The scrolling address and status fields
scroll through the address and status
of all DeviceNet slaves that are
faulted. This scrolling includes the
Anybus-X scanner itself.
If there are no faulted nodes, both the
scrolling address and status are set to
0.
The scrolling fields change once a sec-
ond.
43 1 USINT Scrolling Status
44 20 USINT[20] Reserved
64 64 USINT[64] Node Status Table The current status of each DeviceNet
slave node. Each array element is the
status of the node at the corresponding
MAC ID.
If a node is not configured in the Any-
bus-X scan list, the status value will
be set to 0.
The Anybus-X scanner status appears
at the entry associated with the Any-
bus-X MAC ID.
See Table 10-6, “Node Status Codes,”
on page 10-5 for a list of status codes.
Byte
Offset
Size
in Bytes
Data Type Name Description
Table 6-7 Status Assembly Format (Continued)
