Modbus/TCP 7-6
© 2005 HMS Industrial Networks AB7607 User manual
The Command register is a bit string with the following bit definitions.
Bit Description
0 Local Run Mode. Used in conjunction with the Sys-
tem Run Mode bit in the Run/Idle register to deter-
mine the run mode of the . Both bits must be set for
the to be in Run mode; otherwise the module will be
in Idle mode.
1 Fault. Sets a fault condition in the .
2 Disable DeviceNet network.
3 Not used.
4 Reset the module.
5-31 Not used.
Table 7-8 Output Command Register Bit Definitions
