SECTION 3 − DEFINITIONS
3-1. Additional Safety Symbols And Definitions
. Some symbols are found only on CE products.
Warning! Watch Out! There are possible hazards as shown by the symbols.
Safe1 2012−05
Drive rolls can injure fingers.
Safe32 2012−05
3-2. Miscellaneous Symbols And Definitions
. Some symbols are found only on CE products.
A
Amperage
V
Voltage
Hz
Hertz Negative
Positive
Direct Current
(DC)
Single Phase Input
Output Voltage Input Off On
Do Not Switch
While Welding
Gas Metal Arc
Welding (GMAW)
Wire Feed
Flux Cored Arc
Welding (FCAW)
Line Connection
U1
Primary Voltage
U
2
Conventional Load
Voltage
Percent
Single Phase
Transformer-
Rectifier
U
0
Rated No Load
Voltage (Average)
I
1
Rated Supply
Current
I
2
Rated Welding
Current
X
Duty Cycle
S
Suitable For
Welding In An
Environment With
Increased Risk Of
Electric Shock
