. A complete Parts List is available at www.HobartWelder.com
OM-923 Page 17
Input6 2011−03 804 122-C
5-7. Connecting 115 Volts Input Power
! Installation must meet all
National and Local Codes −
have only qualified persons
make this installation.
! Special installation may be
required where gasoline or vola-
tile liquids are present − see NEC
Article 511 or CEC Section 20.
1 Plug From Unit
2 Receptacle − NEMA Type 5−15R
(Customer Supplied)
For 115 volt AC input power, a 20
ampere individual branch circuit
protected by time-delay fuses or circuit
breaker is required.
Select extension cord of 12 AWG for up
to 50 ft (15 m) or 10 AWG for 50 up to
100 ft (30 m).
1
2
Notes
Work like a Pro!
Pros weld and cut
safely. Read the
safety rules at
the beginning
of this manual.
