9-15. Troubleshooting − Distortion
Distortion − contraction of weld metal during welding that forces
base metal to move.
Base metal moves
in the direction of
the weld bead.
S-0642
Possible Causes Corrective Actions
Excessive heat input. Use restraint (clamp) to hold base metal in position.
Make tack welds along joint before starting welding operation.
Select lower voltage range and/or reduce wire feed speed.
Increase travel speed.
Weld in small segments and allow cooling between welds.
9-16. Troubleshooting Guide For Semiautomatic Welding Equipment
Problem Probable Cause Remedy
Wire feed motor operates, but
wire does not feed.
Too little pressure on wire feed rolls. Increase pressure setting on wire feed rolls.
Incorrect wire feed rolls. Check size stamped on wire feed rolls, replace to match
wire size and type if necessary.
Wire spool brake pressure too high. Decrease brake pressure on wire spool.
Restriction in the gun and/or assembly. Check and replace cable, gun, tip adapter, and contact
tip if damaged. Check size of contact tip and cable liner,
replace if necessary.
Wire curling up in front of the
wire feed rolls (bird nesting).
Too much pressure on wire feed rolls. Decrease pressure setting on wire feed rolls.
Incorrect cable liner or gun contact tip size. Check size of contact tip and check cable liner length
and diameter, replace if necessary.
Gun end not inserted into drive housing properly. Loosen gun securing bolt in drive housing and push gun
end into housing just enough so it does not touch wire
feed rolls.
Dirty or damaged (kinked) liner. Replace liner.
Welding arc not stable.
Wire slipping in drive rolls. Adjust pressure setting on wire feed rolls. Replace worn
drive rolls if necessary.
Wrong size gun liner or contact tip. Match liner and contact tip to wire size and type.
Incorrect voltage setting for selected wire feed speed on
welding power source.
Readjust welding parameters.
Loose connections at the gun weld cable or work cable. Check and tighten all connections.
Gun in poor shape or loose connection inside gun. Repair or replace gun as necessary.
