. A complete Parts List is available at www.HobartWelders.com
OM-260 273 Page 17
5-10. Connecting Input Power
input4 2012−05 − Ref. 803 766-C / 260 711-B
L1
L2
230 VAC, 1
7
9
Tools Needed:
2
1
L1
L2
1
=GND/PE Earth Ground
6
5
3
4
7
! Installation must meet all National and
Local Codes − have only qualified per-
sons make this installation.
! Disconnect and lockout/tagout input
power before connecting input con-
ductors from unit. Follow established
procedures regarding the installation
and removal of lockout/tagout
devices.
! Always connect green or green/yellow
conductor to supply grounding termi-
nal first, and never to a line terminal.
See rating label on unit and check input volt-
age available at site.
1 Input Power Cord
2 Disconnect Device (switch shown in the
OFF position)
3 Disconnect Device Grounding Terminal
4 Disconnect Device Line Terminals
5 Black And White Input Conductor (L1
And L2)
6 Green Or Green/Yellow Grounding
Conductor
Connect green or green/yellow grounding
conductor to disconnect device grounding
terminal first.
Connect input conductors L1 and L2 to dis-
connect device line terminals.
7 Over-Current Protection
Select type and size of over-current protec-
tion using Section 5-9 (fused disconnect
switch shown).
8 Receptacle (NEMA 6-50R)
Connect receptacle as shown.
Close and secure door on disconnect device.
Follow established lockout/tagout proced-
ures to put unit in service.
9 Plug (NEMA 6-50P)
Connect plug to receptacle.
To Next Page
