1. Introduction
This user’s manual is designed with the purpose of providing guidelines and instructions for the machine
user or system designer while operating, installing, wiring and servicing the UST sensor (UST-05LN,
UST-05LA).
1.1 About this document/manual
The UST’s features, installation and handling method are described in this document.
Make sure to read carefully and understand this document before installation, wiring, operation,
inspection and maintenance.
User should have a copy of this document at an easy-to-access place for quick reference.
Any modifications or disassembly of the UST is prohibited. Modifications will affect sensor
performance and detection capability that could lead to critical injury and death.
Any modifications or disassembly of the UST will void the warranty.
All information in this user’s manual is subject to change without prior notice. For the latest
information visit our company’s website http://www.hokuyo-aut.jp
1.2 Applicable products
This document is for the following sensor models.
UST-05LN
UST-05LA
1.3 Special markings and symbols
Markings and symbols are used in this document to alert the user about safety-related issues. Follow the
instructions of these special markings and symbols to ensure safety during the operation.
Procedures that could lead to dangerous situation, critical injury or death if not
carried out properly
Procedures that could lead to dangerous situation, serious injury or physical
damage if not carried out properly
Points that should be considered for the proper operation
