HOKUYO AUTOMATIC UST-05LN - Daily inspection

Document No: C-41-02490-9
43
8.3 Daily inspection
Below Table 8-3 shows an example of the items that should be checked during daily inspection.
Table 8-3 Daily inspection list
No.
Check item
Condition
Remark
Yes
No
1
UST is correctly mounted at the intended location and
screws are firmly fastened
2
All the wirings are correctly connected
3
When the test piece is placed in the detection area
Output 1 to 3 switch from ON state to OFF state
4
When the test piece is removed from the detection area
Output 1 to 3 switch from OFF state to ON state
5
Area switching is according to input signal
6
Predetermined system operation is carried out as expected
* Must check items 3 and 4 for all the areas.
