HOKUYO AUTOMATIC UST-05LN - Components of UST-05 LN;UST-05 LA

Document No: C-41-02490-9
8
3.2 Components of UST-05LN/UST-05LA
Figure 3-1 shows the components of UST-05LN/UST-05LA
Figure 3-1 UST-05LN/UST-05LA components
Figure 3-2 shows the scanning range and detection zone origin of the UST, while figure 3-3 shows its
detection plane.
Cable
Optical window
Housing
LED display
USB Connector
