Holtek HT66F002 User Manual

Rev. 1.71 112 April 11, 2017 Rev. 1.71 113 April 11, 2017
HT66F002/HT66F0025/HT66F003/HT66F004
Cost-Effective A/D Flash MCU with EEPROM
HT66F002/HT66F0025/HT66F003/HT66F004
Cost-Effective A/D Flash MCU with EEPROM
MFI0 Register – HT66F002/HT66F0025/HT66F003
Bit 7 6 5 4 3 2 1 0
Name — — STMA0F STMP0F — — STMA0E STMP0E
R/W — — R/W R/W — — R/W R/W
POR — — 0 0 — — 0 0
B
it7~6 Unimplemented,readas"0"
Bit5 STMA0F:STMComparatorAmatchinterruptrequestag
0:Norequest
1:Interruptrequest
Bit4 STMP0F:STMComparatorPmatchinterruptrequestag
0:Norequest
1:Interruptrequest
Bit3~2 Unimplemented,readas"0"
Bit1 STMA0E:STMComparatorAmatchinterruptcontrol
0:Disable
1:Enable
B
it0 STMP0E:STMComparatorPmatchinterruptcontrol
0:Disable
1:Enable
MFI0 Register – HT66F004
Bit 7 6 5 4 3 2 1 0
Name PTMA1F PTMP1F PTMA0F PTMP0F PTMA1E PTMP1E PTMA0E PTMP0E
R/W R/W R/W R/W R/W R/W R/W R/W R/W
POR 0 0 0 0 0 0 0 0
Bit7 PTMA1F:TM1ComparatorAmatchinterruptrequestag
0:Norequest
1:Interruptrequest
Bit6 PTMP1F:TM1ComparatorPmatchinterruptrequestag
0:Norequest
1:Interruptrequest
Bit5 PTMA0F:TM0ComparatorAmatchinterruptrequestag
0:Norequest
1:Interruptrequest
Bit4 PTMP0F:TM0ComparatorPmatchinterruptrequestag
0:Norequest
1:Interruptrequest
Bit3 PTMA1E:TM1ComparatorAmatchinterruptcontrol
0:Disable
1:Enable
Bit2 PTMP1E:TM1ComparatorPmatchinterruptcontrol
0:Disable
1:Enable
Bit1 PTMA0E:TM0ComparatorAmatchinterruptcontrol
0:Disable
1:Enable
Bit0 PTMP0E:TM0ComparatorPmatchinterruptcontrol
0:Disable
1:Enable
