Holtek HT66F002 User Manual

Rev. 1.71 62 April 11, 2017 Rev. 1.71 63 April 11, 2017
HT66F002/HT66F0025/HT66F003/HT66F004
Cost-Effective A/D Flash MCU with EEPROM
HT66F002/HT66F0025/HT66F003/HT66F004
Cost-Effective A/D Flash MCU with EEPROM
• PBSR Register – HT66F003
Bit 7 6 5 4 3 2 1 0
Name — — PBS5 PBS4 PBS3 PBS2 PBS1 PBS0
R/W — — R/W R/W R/W R/W R/W R/W
POR — — 0 0 0 0 0 0
B
it7~6 Unimplemented,readas“0”
B
it5 PBS5: Pin-SharedControlBit
0:PB5
1:PTP1
Bit4 PBS4: Pin-SharedControlBit
0:PB4
1:PTP1B
Bit3 PBS3: Pin-SharedControlBit
0:PB3
1:PTP1
Bit2 PBS2: Pin-SharedControlBit
0:PB2
1:PTP1B
Bit1 PBS1: Pin-SharedControlBits
0:PB1/PTCK1
1:STP0B
Bit0 PBS0:Pin-SharedControlBit
0:PB0/PTP1I
1:VREFO
• PBSR Register – HT66F004
Bit 7 6 5 4 3 2 1 0
Name — PBS6 PBS5 PBS4 PBS3 PBS2 PBS1 PBS0
R/W — R/W R/W R/W R/W R/W R/W R/W
POR — 0 0 0 0 0 0 0
Bit7 Unimplemented,readas“0”
Bit6 PBS6:Pin-SharedControlBit
0:PB6
1:PTP1B
Bit5 PBS5:Pin-SharedControlBit
0:PB5
1:PTP0B
Bit4 PBS4:Pin-SharedControlBit
0:PB4
1:CLO
Note:PBS4isvalidwhenCOM2EN=0
Bit3 PBS3:Pin-SharedControlBit
0:PB3
1:AN7
Note:PBS3isvalidwhenCOM3EN=0
Bit2 PBS2:Pin-SharedControlBit
0:PB2/PTCK0
1:AN2
Bit1 PBS1:Pin-SharedControlBits
0:PB1/INT1
1:AN1
Bit0 PBS0:Pin-SharedControlBit
0:PB0/INT0
1:AN0
