18-3
LIGHTS/METERS/SWITCHES
BULB
SCREWS
TURN SIGNAL
LIGHT ASSEMBLY
TURN SIGNAL LIGHT
FRONT TURN SIGNAL LIGHT
BULB REPLACEMENT
Remove the handlebar front cover (page 2-7).
Remove front turn signal bulb holder by turning
counterclockwise.
Remove bulb by pressing in and turning counter clock
wise and replace it with a new one.
Installation is in the reverse order of removal.
FRONT TURN SIGNAL UNIT REPLACEMENT
Remove the handlebar front cover (page 2-7).
Remove the screws (3 nos.) and front turn signal light
assembly.
Installation is in the reverse order of removal.
