2-10
FRAME/BODY PANELS/EXHAUST SYSTEM
Insert the bolts (2 nos.) and tighten the nuts (2 nos.).
Installation is in the reverse order of removal.
SIDE STAND
Lift up the body cover. (page 2-3).
Remove the floor mat from the floor panel.
Remove the floor panel (page 2-5).
Remove the floor under cover (page 2-6).
BOLT
BOLTS
Align the hole of side stand bracket with matching holes
in the frame.
ALIGN
FLOOR UNDER COVER
FLOOR PANEL
FLOOR PANEL
To Next Page
