Honda Activa SCV110 User Manual

18-8
LIGHTS/METERS/SWITCHES
RIGHT SIDE:
LEFT SIDE:
HANDLEBAR SWITCHES
Remove the front handlebar cover (page 2-7).
Disconnect the handlebar switch connectors.
Check the continuity between the wire terminals of the
handlebar switch connector.
Continuity should exist between the color coded wire ter-
minals as follows:
RIGHT HANDLEBAR SWITCHES
STARTER SWITCH
LIGHTING SWITCH
LEFT HANDLEBAR SWITCHES
TURN SIGNAL SWITCH
DIMMER SWITCH
HORN SWITCH
FREE
PUSH
G/Y
Y/R
OFF
ON
Br
Y
Colour
Position
Colour
Position
L
N
R
Lb
O Gr
LO
N
HI
Br
W Bu
FREE
PUSH
Bl
Lg
Colour
Position
Colour
Position
Colour
Position
