7)
Hold the crankshaft with the crankshaft holder and tighten
the
30
mm lock nut to the specified torque.
TORQUE:
69
N*m
(7.0kgf
ern,
51
Ibf
Oft)
8)
Make sure that the woodruff key on the crankshaft aligns
with the center line
of
the cylinder as shown (woodruff
key should align with the
“I”
mark on the crankcase
cover).
If
necessary, turn the crankshaft clockwise using
the crankshaft holder.
9)
Che
10)lnstall the timing belt on the timing belt drive pulley first
and then on the driven pulley taking care not to allow the
alignment marks to come out of alignment.
[41 CRANKSHAFT
r-i
079232A00100
k the timing belt, replace the timing belt if it is worn
or damaged. Check the timing belt and the related parts
for oil and grease.
If
contaminated with oil or grease,
clean the parts and replace the timing belt with new one.
CENTERLGOF
hh
%I
1
