138 8680i User Guide
GS1 Composite Code Message Length
Scan the bar codes below to change the message length. Refer to Message Length
Description (page 94) for additional information. Minimum and Maximum
lengths = 1-2435. Minimum Default = 1, Maximum Default = 2435.
GS1 Emulation
The 8680i can automatically format the output from any GS1 data carrier to emu-
late what would be encoded in an equivalent GS1-128 or GS1 DataBar symbol.
GS1 data carriers include UPC-A and UPC-E, EAN-13 and EAN-8, ITF-14, GS1-
128, and GS1-128 DataBar and GS1 Composites. (Any application that accepts
GS1 data can be simplified since it only needs to recognize one data carrier type.)
If GS1-128 Emulation is scanned, all retail codes (U.P.C., UPC-E, EAN8, EAN13)
are expanded out to 16 digits. If the AIM ID is enabled, the value will be the GS1-
128 AIM ID, ]C1 (see Symbology Charts on page 221).
If GS1 DataBar Emulation is scanned, all retail codes (U.P.C., UPC-E, EAN8,
EAN13) are expanded out to 16 digits. If the AIM ID is enabled, the value will be the
GS1-DataBar AIM ID, ]em (see Symbology Charts on page 221).
If GS1 Code Expansion Off is scanned, retail code expansion is disabled, and UPC-
E expansion is controlled by the UPC-E0 Expand (page 117) setting. If the AIM ID
is enabled, the value will be the GS1-128 AIM ID, ]C1 (see Symbology Charts on
page 221).
If EAN8 to EAN13 Conversion is scanned, all EAN8 bar codes are converted to
EAN13 format.
Default = GS1 Emulation Off.
