214 8680i User Guide
Required Safety Labels
8680i Wearable Mini Mobile Computer
Electrical
Voltage 4.2 volts (BAT-SCN03 standard capacity battery)
4.35 volts (BAT-SCN02 high capacity battery)
Current Draw 1A output for each port
Charge Time 4 hours at room temperature of 46°F to 91°F (8°C to
33°C)
8 hours at a temperatures lower than 46°F (8°C) or
higher than 91°F (33°C)
Environmental
Operating Temperature 32° F to +122° F (0° C to +50° C)
Storage Temperature -4° F to +140° F (-20° C to +60° C)
Humidity Up to 95% non-condensing
Mechanical Drop Operational after 6 drops from 2.9 feet
(0.9 m) to concrete
Vibration 2G Peak from 2Hz to 200Hz
ESD Sensitivity Up to 15kV direct air
Up to 8 kV contact and indirect
Parameter (Continued) Specification
Compliance and
laser label location
