Revision 10 ControlEdge HC900 Process & Safety Controller User and Installation Manual 57
May 2019
Table 4 – Power Applied, by Module Type
Module
ControlEdge
HC900 Hardware
Power (Watts)
Field Power
(Watts)
Total Power
(Watts)
Controller C30 and C30S
6.0
0.0
6.0
Controller C50 and C50S
6.0
0.0
6.0
Controller C70 and C70S
7.1
0.0
7.1
Controller C75 and C75S
7.8
0.0
7.8
Redundancy switch module (RSM)
0.1
0.0
0.1
Power Status Module (PSM)
0.1
0.0
0.1
Scanner 1 Port (S50/S50S)
3.9
0.0
3.9
Scanner 2 Port (S75/S75S)
5.0
0.0
5.0
Analog Input (Universal)
0.8
0.0
0.8
Analog Input (High level)
1.6
0.0
1.6
Analog Output (4 points)
5.1
0.0
5.1
Analog Output (8 pts. internal 24V)
9.4
0.0
9.4
Analog Output (8 pts. external 24V)
1.1
8.3
9.4
Analog Output (16 pts. internal 24V)
18.3
0.0
18.3
Analog Output (16 pts. external 24V)
1.7
16.6
18.3
Contact Input
1.6
0.0
1.6
Relay Output
3.0
0.0
3.0
16 pt DC In (@ 24V)
0.7
2.6
3.3
16 pt DC In (@ 32V)
0.7
5.1
5.7
32 pt DC In (@ 24V)
1.1
3.1
4.2
32 pt DC In (@ 32V)
1.1
5.1
6.2
16 pt DC Out
1.7
1.2
2.9
32 pt DC Out
1.2
1.8
3.0
AC In (@120V)
0.7
1.9
2.6
AC In (@240V)
0.7
7.7
8.3
AC/DC In
0.7
7.7
8.3
AC Out
1.1
12.0
13.1
PFQ
6.7
0.1
6.8
Universal IO (16 Pts)
2.45
4.5
6.95
