70 ControlEdge HC900 Process & Safety Controller User and Installation Manual Revision 10
May 2019
5. Rack Installation
5.1. Overview
This section contains procedures for installing one or more ControlEdge HC900 Controllers. It is
recommended that the information in this section be reviewed before beginning the installation.
Familiarity with the overall procedure will help to prevent errors and will promote efficiency in general.
ABS installations require additional protection from the environment and must be installed in a grounded
metal enclosure.
Note: Un-configured racks will not be detected in 100ms base cycle mode and it is not recommended to
connect to IO network/switch
Tools Required
The primary tools required during installation are listed in Table 6.
Table 6 – Installation Tools
Item
Description
Comments
1
2
3
4
5
6
7
8
9
10
11
Common tools
 Wire strippers
 Crimper
Screwdrivers
 Small flat-tip
 Small/medium flat-tip or Phillips
 Large (long blade)
Other
 Electric drill, with drill bits for #10 or M4
screws, and with drill-bit extender
 Vacuum cleaner, brush
 Pen, ball-point or felt-tip, for entering data on
labels for I/O modules)
 Multi-Meter (Volt/Ohms/Amps)
 Soldering pencil or gun (for attaching filter
capacitors to I/O wiring shields)
Special tools
 Precision meters
For Power Supply and for I/O Wiring
For Terminal Lugs on Power Supply
wiring and on I/O wiring shields
For Euro-style Terminal Blocks
For Barrier style Terminal blocks);
also for captured screws in Terminal
Blocks
For use as I/O Module extractor
For rack mounting
For use during and after drilling
operations
For entering data on labels for I/O
modules
For safety checks and for equipment
test
For attaching filter capacitors on I/O
wiring shields
(If required) for testing Analog
calibration; refer to Analog Calibration
in this manual.
