Honeywell AQ25A Series User Manual

AQ252 Universal Injection/Mixing Boiler Reset Control Panels
69-1986—02 24
APPENDIX
The appendix provides AQ252 Control Panel user interface
information for the:
— The Home Page
— Programming menus (User and Installer)
— Programming menu structure (User and Installer). See
page 40.
Home Page
The Home Page is the default display for the control panel. It
provides general information on system water and outdoor
temperatures, and program schedule mode and day and time.
The Home Page display may be Simple (3-line) or Detailed
(10-line), as illustrated in Fig. 23. The Home Page display type
is configured from the Installer Menu.
Press the Home button on the keypad to display the Home
Page.
NOTES:
1. PLS SET DAY/TIME displays after a power outage
of more than 4 hours.
2. PROGRAM displays the current active program
(Leave, Return, Sleep, Wake, Occ, or Unocc).
3. TARGET displays the current temperature or
indicates the system is in a warm water shutdown
(WWSD) status.
4. When “- -” is displayed instead of a temperature
value (e.g., TARGET: - -), this means that there is
no call for heat from either space heating, DHW, or
Heat Demand zones at the moment.
Fig. 23. Home Page display (Simple and Detail) and keypad.
Programming Menus
There are two programming menus, User and Installer. The
Installer Menu begins on page 31.
User Menu
The User Menu can be accessed at any time by pressing the
Menu button on the keypad.
This menu allows the building owner to:
• View the System Status and Statistics.
• Set the display preferences, date, and time.
• Edit the Zone settings, including setpoint temperatures for
each zone.
• Edit the Setback temperatures for each zone for the WAKE,
LEAVE, RETRN (return), and SLEEP programs.
Refer to Table 5 beginning on page 25 for the following User
Menu selections:
— System Status (page 25)
— Preferences/Time (page 25)
— Zone Settings (page 26)
• All zones
• Single zone for Ambient, Floor, or Ambient/Floor
settings
— Program Settings (page 29)
— Statistics – refer to page 30.
NOTE: An illustration of the complete User Menu is on
page 40.
M27699
WEDNESDAY 9:30A
PROGRAM: LEAVE  RETRN SLEEP WAKE OCC UNOCC
OUTDOOR: -5
TARGET: 180  WWSD -
-
BOILER: 180
RETURN: 160
SECONDARY: 100
SEC TARGET: 100  WWSD -
-
DHW: 100
ZONE COUNT: 31
WEDNESDAY 9:30A
PROGRAM: LEAVE
OUTDOOR: -5
Menu
Home
KEYPAD
HOME PAGE (SIMPLE)
HOME PAGE (DETAIL)
LCD DISPLAY
